Products Personal dosimeters Personal gamma radiation dosimeter DKG-05D

DKG-05D

Personal gamma-radiation dosimeter

Direct-reading electronic dosimeter to measure personal dose equivalent (individual dose equivalent) Hp(10) and  personal dose equivalent rate Hp(10) of gamma (photon) radiation.
Can be used individually or as a part of the automated personal dosimetry monitoring system for nuclear facility personnel.

Purpose:

Routine, planned, time-based, on-call, emergency, accident and post-accident personal dosimetry monitoring at nuclear facilities such as: nuclear power plants and nuclear fuel production, clinics of nuclear medicine, research laboratories, other facilities with the use of sources of ionized radiation.
Also suitable for First Responders, Disease Control and Prevention Service, customs check-points.

Features:

  • Built-in display (LCD) with backlit for direct indication of:
       - personal dose equivalent rate;
       - personal dose equivalent collected from the moment of dosimeter switch-on;
       - total personal dose equivalent collected from the moment of dosimeter reset (archive zeroing).
  • Internal nonvolatile memory.
  • Self-check of dosimeter condition and low-battery level with indication on LCD.
  • Visual and sound alarm on exceeding of alarm thresholds.
  • Connection to PC using US-05-01 or UZS-01D readers for parameters configuration, alarm thresholds setup and archive reading.
  • User access control to parameters changing and archive reading. Unauthorized users cannot change or reset the collected dose information.
  • Power supply from rechargeable or non-rechargeable battery AAA-size.
  • Rigid shock-proof enclosure suitable for severe duty conditions.
  • Pocket clip on the back side.

Scope of supply:

  • DKG-05D personal dosimeter.
  • Rechargeable or non-rechargeable battery.

Options on request:

  • ZU-1M single battery charger for one dosimeter.
  • KZU-28 battery charger for 28 dosimeters charging at a time.
  • US-05-01 individual reader (with the function of battery charging) with Software “STAND”.
  • UZS-01D universal reader for use inside automated personal dosimetry monitoring system.
  • Software “IDK” for use with UZS-01D reader inside automated personal dosimetry monitoring system.

Automated personal dosimetry monitoring system:

DKG-05D and DVS-02D personal dosimeters, in a complete set with chargers, readers, PC and software “IDK” are able to form an automated personal dosimetry monitoring system. The design of the system is bespoke and depends on the number of personnel, working schedule, environment, application, etc. Contact us for more information in case of interest.
